Oxygen Concentrator Circuit Board
$30.90
The oxygen concentrator circuit board is the key control and monitoring component in oxygen concentrator systems. Designed with stability, precision, and long-term durability, this PCB supports real-time and precise oxygen concentration monitoring and system diagnostics to ensure optimal oxygen purity and user safety.
Shipping fee and delivery date to be negotiated. Send inquiry for more details.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Claim a refund if your order is missing or arrives with product issues, our support team would deal with your refund within 24 hours.
| Layer Counts | 4L |
| Base Material | FR4 |
| Board Thickness(mm) | 1.6mm |
| Max board size(mm) | 570*850mm |
| PCB size tolerance | ±0.2mm |
| Min. Hole Size | 0.15mm |
| Min. Line Width | 0.4mil |
| Copper Weight | 2oz |
| Surface Finish | HASL |
| Certificate | UL, IPC-6012, RoHS, ISO 9001, ISO14001 |
Oxygen Concentrator Circuit Board
| 5 star | 0% | |
| 4 star | 0% | |
| 3 star | 0% | |
| 2 star | 0% | |
| 1 star | 0% |
Sorry, no reviews match your current selections
Questions & Answers
1. What functions does the Oxygen Concentrator Circuit Board control?
The oxygen concentrator circuit board controls: oxygen flow regulation, sensor monitoring(like oxygen purity and temperature), compressor control, user interface, and other functions. We support customizing different features for your PCB.
2. Can this oxygen concentrator PCB support wireless or Bluetooth functions?
Yes, we can design the PCB with Bluetooth and Wifi modules, achieving wireless data transmission and remote monitoring for users and healthcare providers. If you demand smart health tracking or IoT integration, this feature is super useful.
3. What types of sensors can be integrated with this oxygen concentrator PCB?
This oxygen concentrator can integrate with oxygen concentration sensors, flow sensors, temperature sensors, pressure sensors, and more. Contact our expert and tell us your design requirements to get your best PCB solutions.
4. Can I use this board in portable oxygen concentrators?
Yes. The board is feasible for portable or wearable oxygen concentrators. Its compact size, low power consumption, and optimized layout meet the thermal and space requirements of portable medical devices.
5. Can I customize backup battery support on the PCB?
Yes. We design the PCB with integrated backup battery circuits to ensure user safety and continuous operations during power outages or mobility needs.
6. What is your typical lead time?
1-2 days. We have our own warehouse and stock in large quantities.
7. Can you support both prototyping and mass production?
Yes, we support small batch prototyping, mid- and large-scale production for various PCBs.
